Stroke [mm]
|
50 |
|
Piston diameter
|
Equivalent diameter |
|
Dampening
|
No dampening |
|
installation position
|
arbitrary |
|
Principle of operation
|
Pressing |
|
Construction set up
|
Piston |
|
Position detection
|
without |
|
Anti-twist lock / guide
|
Rectangular piston rod |
|
Operating pressure [bar]
|
2.5 to 6 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
ambient temperature [°C]
|
0 to 60 |
|
Theoretical force at 6 bar, flow [N]
|
49,0 |
|
Theoretical minimum spring rest force [N]
|
10,6 |
|
Theoretical maximum spring return force [N]
|
13,6 |
|
Product weight [g]
|
145 |
|
Fastening type
|
With Cross-bore |
|
Pneumatic connection
|
plug / push in nipple PK-3 |
|
Cover material
|
Aluminium |
|
Seals material
|
TPE-U(PU) |
|
Housing material
|
Aluminium |
|
Piston rod material
|
Nickel- |
|
Weight
|
145 g / Pcs |
|
GTIN
|
4052568137397 |
|
Customs duty number
|
84123100 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: EZH/DZF/DZH (english) , Data sheet |
