size
|
20 |
|
Ausführung Formgreifkappe
|
Standard |
|
Stroke [mm]
|
66 |
|
Min. diameter to be gripped [mm]
|
12 |
|
Max. diameter to be gripped [mm]
|
38 |
|
installation position
|
arbitrary |
|
Principle of operation
|
double acting |
|
Gripper function
|
Adaptiv |
|
Construction set up
|
zwangsgeführter Bewegungsablauf |
|
Guide
|
Base guide |
|
Position detection
|
For proximity switch |
|
Operating pressure actuator [bar]
|
1 to 8 |
|
Betriebsdruck Kappe [bar]
|
0,07 bis 0,1 |
|
Berstdruck Kappe [bar]
|
0,3 |
|
Max. working frequency gripper [hz]
|
1 |
|
Retraction time [ms]
|
290 |
|
Extension time [ms]
|
270 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation not possible |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
ambient temperature [°C]
|
0 to 60 |
|
Mass inertia [Kilogramm ]
|
1,29 |
|
Guideline payload [KGM]
|
1 |
|
Product weight [g]
|
475 |
|
Fastening type
|
nach ISO 9409 |
|
Pneumatic connection
|
M5 |
|
Material information
|
LABS containing materials included |
|
Cap material
|
VMQ (Silicone) |
|
Housing material
|
Anodised aluminium |
|
Weight
|
475 g / Pcs |
|
Customs duty number
|
84799070 |
|
Manufacturer
|
Festo |
