Stroke [mm]
|
125 |
|
Piston diameter
|
20 mm |
|
Based on standard
|
ISO 6432 |
|
Dampening
|
PPS: Self-setting pneumatic end position dampening |
|
installation position
|
arbitrary |
|
Construction set up
|
Piston |
|
Position detection
|
For proximity switch |
|
Operating pressure [bar]
|
1 to 10 |
|
Principle of operation
|
double acting |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Corrosion resistant class KBK
|
4 - particularly severe corrosion stress |
|
Food compatibility
|
See expanded material information |
|
ambient temperature [°C]
|
0 to 80 |
|
Maritime classification
|
see Certificate |
|
Theoretical force at 6 bar, Return flow [N]
|
158 |
|
Theoretical force at 6 bar, flow [N]
|
188 |
|
Moving mass at 0 mm stroke [g]
|
42,1 |
|
Weight supplement per 10 mm stroke [g]
|
7,2 |
|
Base weight at 0 mm stroke [g]
|
310 |
|
Supplement moved mass per 10 mm stroke [g]
|
3,9 |
|
Fastening type
|
With Accessories |
|
Pneumatic connection
|
G1/8 |
|
Material information
|
RoHs compliant |
|
Cover material
|
High-alloyed stainless steels |
|
Piston rod material
|
High-alloyed stainless steels |
|
Cylinder tube material
|
High-alloyed stainless steels |
|
Weight
|
390 g / Pcs |
|
GTIN
|
4052568298104 |
|
Customs duty number
|
84123100 |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Corrosion-resistant cylinders (english) , Data sheet |
