size
|
8 |
|
Stroke [mm]
|
14 |
|
Dampening
|
self-adjusting |
|
installation position
|
arbitrary |
|
Fine adjustment [mm]
|
0,03 |
|
Position detection
|
For proximity switch |
|
Max. impact speed [m/s]
|
3 |
|
Rest time short [s]
|
<= 0,2 s |
|
Rest time long [s]
|
< 1 s |
|
Principle of operation
|
Pressing |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
ambient temperature [°C]
|
0 to 60 |
|
Dampening length [mm]
|
14 |
|
Max. impact force [N]
|
500 |
|
Max. energy consumption per stroke [J]
|
3 |
|
Max. energy consumption per hour [J]
|
21.000 |
|
Max. residual energy [J]
|
0,02 |
|
Reset force [N]
|
3,5 |
|
Product weight [g]
|
110 |
|
Fastening type
|
With locking nut |
|
Material information
|
Copper and PTFE-free |
|
Seals material
|
NBR |
|
Housing material
|
brass |
|
Piston rod material
|
High-alloyed steel |
|
Weight
|
110 g / Pcs |
|
GTIN
|
4052568153175 |
|
Customs duty number
|
84879059 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Cushioning components (english) , Data sheet |
