Permission
|
RCM mark |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Material information
|
LABS containing materials included |
|
Measured parameter
|
Relative pressure |
|
Measurement process
|
Pneumatic electric pressure converter |
|
Operating pressure [bar]
|
-1 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:-:-] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Medium temperature [°C]
|
0 to 60 |
|
ambient temperature [°C]
|
0 to 60 |
|
Switching element function
|
changeover contact |
|
Max. output current [mA]
|
2.500 |
|
electrical connection:
|
4 pin |
|
Fastening type
|
With throughway bores |
|
installation position
|
arbitrary |
|
Pneumatic connection
|
M5 |
|
Product weight [g]
|
56 |
|
Housing material
|
PA |
|
Settings range threshold value [bar]
|
-0.8 to -0.2 |
|
Protection category
|
IP20 |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Pressure measurement range [bar]
|
-0.8 to -0.2 |
|
Operating voltage range DC [V]
|
10 to 30 |
|
Switching status indicator
|
LED yellow |
|
Hysteresis [bar]
|
0.08 to 0.2 |
|
Weight
|
56 g / Pcs |
|
GTIN
|
4052568070250 |
|
Customs duty number
|
85369095 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: PEV/VPEV (english) , Data sheet |
