electrical connection:
|
Via connection plate |
|
Protection category
|
IP65 |
|
Corrosion resistant class KBK
|
1 - low corrosion stress |
|
Product weight [g]
|
200 |
|
Material information
|
RoHs compliant |
|
Nominal operating voltage DC [V]
|
24 |
|
Permitted voltage oscillations
|
± 25 % |
|
ambient temperature [°C]
|
-5 to 50 |
|
Permission
|
c UL us - Recognized (OL) |
|
Housing material
|
PA-GF |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Measured parameter
|
Relative pressure |
|
Measurement process
|
Piezoresistive pressure sensor with display |
|
Pressure measurement range [bar]
|
0 to 10 |
|
Pressure measurement range starting value [bar]
|
0 |
|
Pressure measurement range end value [bar]
|
10 |
|
Medium temperature [°C]
|
-5 to 50 |
|
Resolution pressure [bar]
|
0,001 |
|
Accuracy FS []
|
2,5 |
|
Operating voltage range DC [V]
|
18 to 30 |
|
Reverse polarity protection
|
for operating voltage |
|
installation position
|
arbitrary |
|
Pneumatic connection
|
Connection plate |
|
Display type
|
LED |
|
Presentable unit(s)
|
kPa |
|
Switching status indicator
|
LED |
|
Settings range threshold value [%]
|
0 to 100 |
|
Settings range hysteresis [%]
|
0 to 100 |
|
Settings range hysteresis [bar] [bar]
|
0 to 10 |
|
Weight
|
200 g / Pcs |
|
GTIN
|
4052568179564 |
|
Customs duty number
|
90262020 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Valve terminal MPA-S (english) , Data sheet |
