Packing size
|
30 |
|
Information about protection category
|
Depends on connection block |
|
Normal nominal flow [l/min]
|
19 |
|
Normal nominal flow 2-3 [l/min]
|
20 |
|
Flow direction
|
Not reversible |
|
Nominal operating pressure [bar]
|
1,0 |
|
Operating pressure [bar]
|
0 to 1.1 |
|
Valve function
|
3/3 closed monostable |
|
Nominal width [mm]
|
1,3 |
|
Actuation type
|
Electrical |
|
Pneumatic connection 1
|
flange |
|
Pneumatic connection 2
|
flange |
|
Pneumatic connection 3
|
flange |
|
medium
|
Inert gasses |
|
Special features
|
oxygen-compatible acc. to DIN EN 1797 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [6:3:4] |
|
Information about operating and control medium
|
Oiled operation not possible |
|
Max. switching frequency [hz]
|
5 |
|
Medium temperature [°C]
|
-20 to 60 |
|
ambient temperature [°C]
|
-20 to 70 |
|
Bearing temperature [°C]
|
-20 to 70 |
|
Nominal operating voltage DC [V]
|
250 |
|
Operating voltage range DC [V]
|
0 to 250 |
|
Max. power input [mA]
|
5 |
|
Max. electrical power consumption [W]
|
0,001 |
|
Product weight [g]
|
8 |
|
Seals material
|
EPDM |
|
Housing material
|
PA reinforced |
|
Cover material
|
PA reinforced |
|
Material information
|
RoHs compliant |
|
Pitch dimension [mm]
|
17,2 |
|
Dimensions W x L x H
|
17.2 mm x 52.1 mm x 7.2 mm |
|
Fastening type
|
on connection plate |
|
installation position
|
arbitrary |
|
CE certificate (see declaration of conformity)
|
to EU low voltage directive |
|
Weight
|
8 g / Pcs |
|
GTIN
|
4052568296797 |
|
Packing unit
|
30 Pcs |
|
Customs duty number
|
84811099 |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: VEMP (english) , Data sheet |
