Valve function
|
3/2 bistable |
|
Pneumatic connection 1
|
G1/8 |
|
Pneumatic connection 2
|
G1/8 |
|
Actuation type
|
Manually |
|
Fastening type
|
Screwable |
|
Normal nominal flow [l/min]
|
777 |
|
Nominal width [mm]
|
5,7 |
|
Operating pressure [bar]
|
-0.95 to 12 |
|
ambient temperature [°C]
|
-10 to 80 |
|
Housing material
|
Aluminium wrought alloy |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Pitch dimension [mm]
|
24,0 |
|
Sealing principle
|
Soft |
|
installation position
|
arbitrary |
|
Construction set up
|
Sleeve pusher |
|
Control type
|
Direct |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Medium temperature [°C]
|
-10 to 80 |
|
actuating force [N]
|
17 |
|
Product weight [g]
|
17 |
|
Stud material
|
Aluminium wrought alloy |
|
Material information
|
RoHs compliant |
|
Seals material
|
NBR |
|
Weight
|
17 g / Pcs |
|
GTIN
|
4052568107819 |
|
Customs duty number
|
84818069 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: VBOH (english) , Data sheet |
