installation position
|
arbitrary |
|
Reverse polarity protection
|
Bipolar |
|
Additional functions
|
Spark suppression |
|
Signal condition display
|
LED |
|
Nominal operating voltage DC [V]
|
24 |
|
Surge voltage strength [kV]
|
0,8 |
|
Degree of contamination
|
3 |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 60 |
|
Product weight [g]
|
20,0 |
|
electrical connection:
|
Square shape / Open end |
|
Protection line connection
|
Not available |
|
Fastening type
|
on solenoid valve with self-cutting screw |
|
Housing colour
|
#000000 |
|
Material information
|
RoHs compliant |
|
Housing material
|
PA |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Permission
|
RCM mark |
|
Cable length [MTR]
|
1,0 |
|
Max. tightening torque [Nm]
|
0,27 |
|
Line properties
|
For static applications |
|
Min. cable bending radius [mm]
|
34 |
|
Cable set up
|
2x0,25 |
|
Cable diameter [mm]
|
3,4 |
|
Tolerance cable diameter
|
± 0,2 mm |
|
Cable sleeve material
|
TPV |
|
Weight
|
20,0 g / Pcs |
|
GTIN
|
4052568059354 |
|
Customs duty number
|
85371098 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: VUVG (english) , Data sheet |
