Nominal width laval nozzle [mm]
|
1,40 |
|
installation position
|
arbitrary |
|
Ejector characteristic
|
High vacuum |
|
Integrated function
|
Electrical switch on valve |
|
Construction set up
|
T-shape |
|
Operating pressure [bar]
|
1.5 to 8 |
|
max. vacuum [%]
|
85 |
|
Power-on time
|
100% |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation not possible |
|
Medium temperature [°C]
|
0 to 40 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
0 to 40 |
|
electrical connection:
|
Plug |
|
Fastening type
|
with female thread |
|
Pneumatic connection 1
|
G1/8 |
|
vacuum connection
|
G1/4 |
|
Housing material
|
Aluminium |
|
Product weight [g]
|
212 |
|
Weight
|
212 g / Pcs |
|
GTIN
|
4052568115845 |
|
Customs duty number
|
84141089 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: VAD-M (english) , Data sheet |
