Nominal width laval nozzle [mm]
|
1,5 |
|
installation position
|
arbitrary |
|
Ejector characteristic
|
High vacuum |
|
Construction set up
|
T-shape |
|
Operating pressure [bar]
|
1.5 to 10 |
|
max. vacuum [%]
|
80 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Medium temperature [°C]
|
-20 to 80 |
|
ambient temperature [°C]
|
-20 to 80 |
|
Fastening type
|
With throughway bores |
|
Pneumatic connection 1
|
G3/8 |
|
Pneumatic connection 3
|
G3/8 |
|
vacuum connection
|
G3/8 |
|
Material information
|
Copper and PTFE-free |
|
Housing material
|
Aluminium die casting |
|
Weight
|
155 g / Pcs |
|
GTIN
|
4052568009465 |
|
Customs duty number
|
84141089 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: VAD/VAK (english) , Data sheet |
