Actuation type
|
Electrical |
|
installation position
|
arbitrary |
|
Power-on time
|
100% |
|
Insulation material class
|
F |
|
Coil characteristic value
|
110 V AC: 50 Hz, pull-in power 6.9 VA, holding power 4.1 VA |
|
Permitted voltage oscillations
|
± 10 % |
|
ATEX gas category
|
II 3G |
|
Ex ignition protection type gas
|
Ex nA IIC T5/T4 X Gc |
|
ATEX dust category
|
II 3D |
|
Ex ignition protection type dust
|
Ex tc IIIC T95°C/T105°C X Dc |
|
Ex ambient temperature
|
-20°C <= Ta <= +60°C |
|
Certified awarding point
|
DNVGL-TAA000011J |
|
CE certificate (see declaration of conformity)
|
to EU EX protection directive (ATEX) |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Protection category
|
IP65 |
|
Product weight [g]
|
95 |
|
electrical connection:
|
Wiring diagram Form A acc. to EN 175301-803 |
|
Material information
|
RoHs compliant |
|
ambient temperature [°C]
|
-20 to 60 |
|
Fastening type
|
With Knurled nut |
|
Winding material
|
Copper |
|
Insulation material class of the paint wire
|
H |
|
Maritime classification
|
see Certificate |
|
Housing material
|
plastic |
|
Plug contacts material
|
Brass |
|
Weight
|
95 g / Pcs |
|
Customs duty number
|
85059029 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Solenoid coils (english) , Data sheet |
