Actuation type
|
Electrical |
|
installation position
|
arbitrary |
|
Power-on time
|
100% |
|
Insulation material class
|
F |
|
ATEX gas category
|
II 2G |
|
Ex ignition protection type gas
|
Ex ia IIC T6, T4 Ga |
|
ATEX dust category
|
II 2D |
|
Ex ignition protection type dust
|
Ex tbIIIC T80°C,T130°C Db IP65 |
|
Ex protection approval outside of the EU
|
EPL Db (BR) |
|
Ex ambient temperature
|
T4,T130°C:-40°C<=Ta<=+85°C |
|
Certified awarding point
|
DNV 15.0188 |
|
CE certificate (see declaration of conformity)
|
to EU EX protection directive (ATEX) |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Protection category
|
IP65 |
|
Product weight [g]
|
114 |
|
electrical connection:
|
Wiring diagram Form A acc. to EN 175301-803 |
|
Material information
|
RoHs compliant |
|
ambient temperature [°C]
|
-20 to 50 |
|
Fastening type
|
With Knurled nut |
|
Winding material
|
Copper |
|
Required power input [A]
|
>= 27 mA |
|
Max. input voltage [V]
|
28 |
|
Max. input current [A]
|
0,115 |
|
Effective capacity
|
Negligibly small |
|
Effective inductivity
|
Negligibly small |
|
Insulation material class of the paint wire
|
H |
|
Maritime classification
|
see Certificate |
|
Housing material
|
plastic |
|
Plug contacts material
|
Brass |
|
Weight
|
114 g / Pcs |
|
Customs duty number
|
85059029 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Solenoid coils (english) , Data sheet |
