installation position
|
arbitrary |
|
Min. tightening time [ms]
|
12 |
|
Power-on time
|
100% |
|
Coil characteristic value
|
24 V DC: 11,9 W |
|
Permitted voltage oscillations
|
± 10 % |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-20 to 50 |
|
Product weight [g]
|
150 |
|
electrical connection:
|
Wiring diagram Form A acc. to EN 175301-803 |
|
Fastening type
|
With locking nut |
|
Material information
|
LABS containing materials included |
|
Winding material
|
Copper |
|
Performance factor cos {phi}
|
0.7 |
|
Switching position display
|
no |
|
Permitted frequency oscillations
|
± 10 % |
|
Solenoid material
|
Copper |
|
Max. tightening torque screw connection [Nm]
|
2,0 |
|
Corrosion resistant class KBK
|
4 - particularly severe corrosion stress |
|
Limits ambient and media temperature
|
-20 - 60 °C |
|
Information about protection category
|
In mounted condition |
|
Weight
|
150 g / Pcs |
|
GTIN
|
4052568062828 |
|
Customs duty number
|
85059029 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Solenoid coils (english) , Data sheet |
