installation position
|
arbitrary |
|
Switching position display
|
no |
|
Power-on time
|
100% |
|
Coil characteristic value
|
24 V AC: 50/60 Hz, power 3.85 VA |
|
Permitted voltage oscillations
|
± 10 % |
|
ATEX gas category
|
II 2G |
|
Ex ignition protection type gas
|
Ex mb IIC T5 Gb |
|
ATEX dust category
|
II 2D |
|
Ex ignition protection type dust
|
Ex mb IIIC T95°C Db |
|
Ex protection approval outside of the EU
|
EPL Db (BR) |
|
Ex ambient temperature
|
-30°C <= Ta <= +40°C |
|
Certified awarding point
|
DNV17.0013X |
|
CE certificate (see declaration of conformity)
|
to EU EX protection directive (ATEX) |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
Protection category
|
IP65 |
|
Product weight [g]
|
170 |
|
electrical connection:
|
3-wire |
|
Material information
|
RoHs compliant |
|
Solenoid material
|
aluminium |
|
Min. tightening time [ms]
|
10 |
|
ambient temperature [°C]
|
-30 to 40 |
|
Fastening type
|
With Knurled nut |
|
Winding material
|
Copper |
|
Permitted frequency oscillations
|
± 5 % |
|
Cable length [MTR]
|
1,00 |
|
Conductor - nominal cross-section [mm²]
|
0,75 |
|
Weight
|
170 g / Pcs |
|
GTIN
|
4052568290276 |
|
Customs duty number
|
85059029 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Solenoid coils (english) , Data sheet |
