Actuation type
|
Electrical |
|
installation position
|
arbitrary |
|
Switching position display
|
no |
|
Power-on time
|
100% |
|
Insulation material class
|
H |
|
Coil characteristic value
|
24 V AC: 50/60 Hz, power 3.5 VA |
|
Permitted voltage oscillations
|
-15 % / +10 % |
|
ATEX gas category
|
II 2G |
|
Ex ignition protection type gas
|
Ex e mb II T6, T5 |
|
ATEX dust category
|
II 2D |
|
Ex ignition protection type dust
|
Ex tD A21 IP65 T80°C, T95°C |
|
Ex protection approval outside of the EU
|
EPL Db (BR) |
|
Ex ambient temperature
|
T5,T95°C: -20°C <= Ta <= +60°C |
|
Certified awarding point
|
NEPSI GYJ111106X |
|
CE certificate (see declaration of conformity)
|
to EU EX protection directive (ATEX) |
|
Corrosion resistant class KBK
|
4 - particularly severe corrosion stress |
|
Protection category
|
IP65 |
|
Product weight [g]
|
580 |
|
electrical connection:
|
Terminal boxes, Cable feed in thread M20x1,5 |
|
Material information
|
LABS containing materials included |
|
Solenoid material
|
PA |
|
Internal fuses
|
Fuse |
|
Weight
|
580 g / Pcs |
|
GTIN
|
4052568217310 |
|
Customs duty number
|
85059029 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Solenoid coils (english) , Data sheet |
