Actuation type
|
Electrical |
|
installation position
|
arbitrary |
|
Switching position display
|
no |
|
Power-on time
|
100% |
|
Insulation material class
|
H |
|
Coil characteristic value
|
14-32 V DC: 0.22 - 1.1 W |
|
Permitted voltage oscillations
|
-15 % / +10 % |
|
ATEX gas category
|
II 2G |
|
Ex ignition protection type gas
|
Ex ia IIC T6, T5 Gb |
|
ATEX dust category
|
II 2D |
|
Ex ignition protection type dust
|
Ex ia IIIC T80°C,T95°C Db |
|
Ex protection approval outside of the EU
|
EPL Db (BR) |
|
Ex ambient temperature
|
T5,T95°C: -30°C <= Ta <= +65°C |
|
Certified awarding point
|
BVS15 ATEXE030X |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Corrosion resistant class KBK
|
4 - particularly severe corrosion stress |
|
Protection category
|
IP64 |
|
Product weight [g]
|
330 |
|
electrical connection:
|
Terminal boxes, Cable feed in thread M20x1,5 |
|
Material information
|
LABS containing materials included |
|
Solenoid material
|
PA |
|
Required power input [A]
|
0,016 |
|
Max. input power
|
1,2 W |
|
Max. input voltage [V]
|
32 |
|
Max. input current [A]
|
0,200 |
|
Effective capacity
|
Negligibly small |
|
Effective inductivity
|
Negligibly small |
|
Weight
|
330 g / Pcs |
|
GTIN
|
4052568210410 |
|
Customs duty number
|
85059029 |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Solenoid coils (english) , Data sheet |
