Build.width [mm]
|
42 |
|
Based on standard
|
ISO 5599-2 |
|
installation position
|
arbitrary |
|
Control air supply
|
external |
|
Operating pressure [bar]
|
-0.9 to 10 |
|
Operating voltage range AC [V]
|
110 |
|
Operating voltage range DC [V]
|
24 |
|
Surge voltage strength [kV]
|
4,0 |
|
Current carrying capacity at 40°C [A]
|
2 |
|
Degree of contamination
|
3 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
CE certificate (see declaration of conformity)
|
to EU low voltage directive |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
371 |
|
Fastening type
|
With throughway bores |
|
Material information
|
RoHs compliant |
|
Connection plate material
|
Aluminium die casting |
|
Connection cross-section [mm²]
|
0.08 to 0.75 |
|
Weight
|
371 g / Pcs |
|
GTIN
|
4052568092498 |
|
Customs duty number
|
84819000 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Valve terminal VTSA / VTSA-F, NPT (english) , Data sheet |
