Pitch dimension [mm]
|
10,5 |
|
Max. number of valve spaces
|
16 |
|
Operating pressure [bar]
|
-0.9 to 10 |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Permission
|
RCM mark |
|
Max. tightening torque Slot rail assembly [Nm]
|
1,5 |
|
Max. tightening torque Valve fastening [Nm]
|
0,45 |
|
Max. tightening torque wall assembly [Nm]
|
1,5 |
|
Product weight [g]
|
312 |
|
Pneumatic connection 1
|
M7 |
|
Pneumatic connection 3
|
M7 |
|
Pneumatic connection 5
|
M7 |
|
Material information
|
RoHs compliant |
|
Connection strip material
|
Aluminium wrought alloy |
|
Support air control connection 12/14
|
M5 |
|
Exhaust control connection 82/84
|
M5 |
|
Pneumatic connection 2
|
M5 |
|
Pneumatic connection 4
|
M5 |
|
Weight
|
312 g / Pcs |
|
GTIN
|
4052568214296 |
|
Customs duty number
|
84819000 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: VUVG (english) , Data sheet |
