Build.width [mm]
|
18 |
|
Based on standard
|
ISO 15407-2 |
|
installation position
|
arbitrary |
|
Operating pressure [bar]
|
3 to 10 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
203,5 |
|
CE certificate (see declaration of conformity)
|
to EU low voltage directive |
|
Fastening type height linking
|
on single connection plate |
|
Control air 14 connection
|
Connection plate Size 18 mm to ISO 15407-2 |
|
Pneumatic connection 1
|
Connection plate Size 18 mm to ISO 15407-2 |
|
Pneumatic connection 4
|
Connection plate Size 18 mm to ISO 15407-2 |
|
Pneumatic connection 5
|
Connection plate Size 18 mm to ISO 15407-2 |
|
Material information
|
RoHs compliant |
|
Plate material
|
Aluminium wrought alloy |
|
Weight
|
203,5 g / Pcs |
|
GTIN
|
4052568219758 |
|
Customs duty number
|
84819000 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Valve terminal VTSA / VTSA-F (english) , Data sheet |
