Build.width [mm]
|
60 |
|
installation position
|
arbitrary |
|
Max. number of valve coils
|
26 |
|
Operating pressure [bar]
|
-0.9 to 10 |
|
Nominal operating voltage DC [V]
|
24 |
|
Permitted voltage oscillations
|
± 10 % |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Product weight [g]
|
2.600 |
|
Support air control connection 12
|
NPT1/8-27 |
|
Support air control connection 14
|
NPT1/8-27 |
|
Pneumatic connection 1
|
NPT1-11 1/2 |
|
Pneumatic connection 3
|
NPT1-11 1/2 |
|
Pneumatic connection 5
|
NPT1-11 1/2 |
|
Material information
|
RoHs compliant |
|
Seals material
|
NBR |
|
Plate material
|
Aluminium wrought alloy |
|
Screws material
|
Steel |
|
Weight
|
2.600 g / Pcs |
|
GTIN
|
4052568229535 |
|
Customs duty number
|
84819000 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Valve terminal VTSA / VTSA-F (english) , Data sheet |
