Valve function
|
3/2 closed monostable |
|
Actuation type
|
Mechanical |
|
Normal nominal flow [l/min]
|
50 |
|
Operating pressure [bar]
|
-0.9 to 8 |
|
Construction set up
|
Ball seat |
|
Reset mode
|
Mechanical spring |
|
Nominal width [mm]
|
1,5 |
|
Sealing principle
|
Soft |
|
Control type
|
Direct |
|
Flow direction
|
Not reversible |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Medium temperature [°C]
|
-10 to 80 |
|
ambient temperature [°C]
|
-10 to 80 |
|
Fastening type
|
With throughway bores |
|
Pneumatic connection 1
|
PK-3 |
|
Pneumatic connection 2
|
PK-3 |
|
Pneumatic connection 3
|
Not recorded |
|
installation position
|
arbitrary |
|
Material information
|
LABS containing materials included |
|
Weight
|
30 g / Pcs |
|
GTIN
|
4052568009120 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Data sheet |
