Data backup
|
Flash memory |
|
Control signal
|
Output error ready |
|
Display
|
3 digits |
|
Operating element
|
3 buttons |
|
Output fuses
|
Electronic |
|
Quantity digital outputs
|
5 |
|
Quantity digital inputs
|
8 |
|
Design outputs
|
No galvanic separation |
|
Design inputs
|
No galvanic separation |
|
Debounce time inputs [ms]
|
20 |
|
Max. power input with proportional valve [A]
|
1,1 |
|
Max. power input without proportional valve [mA]
|
70 |
|
Nominal operating voltage DC [V]
|
24 |
|
Power consumption input [mA]
|
4 |
|
Current carrying capacity per output [mA]
|
100 |
|
Permitted voltage oscillations
|
± 25 % |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Continuous impact strength DIN&EC 68 parts 2-82
|
Tested to severity class 2 |
|
Relative humidity
|
0 - 95 % |
|
Protection category
|
IP65 |
|
Oscillation strength to DIN/IEC 68 part 2-6
|
Tested to severity class 1 |
|
ambient temperature [°C]
|
0 to 50 |
|
Permission
|
RCM mark |
|
Product weight [g]
|
400 |
|
Electrical connection type
|
SUB-D |
|
Electrical connection: proportional valve
|
M9 |
|
Electrical connection: path measurement system
|
M9 |
|
Cable length [MTR]
|
30,0 |
|
Weight
|
400 g / Pcs |
|
GTIN
|
4052568190101 |
|
Customs duty number
|
85371091 |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: SPC11 (english) , Data sheet |
