Permission
|
RCM mark |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Material information
|
LABS containing materials included |
|
Measured parameter
|
Relative pressure |
|
Measurement process
|
Metal thin film pressure sensor |
|
Pressure measurement range starting value [bar]
|
0 |
|
Pressure measurement range end value [bar]
|
25 |
|
Overload range [bar]
|
50 |
|
Operating medium
|
Compressed air to ISO8573-1:2010 [-:-:-] |
|
Medium temperature [°C]
|
-20 to 85 |
|
ambient temperature [°C]
|
0 to 80 |
|
Accuracy FS []
|
1 |
|
Repeatability in ± %FS []
|
0,15 |
|
Control output
|
2xPNP |
|
Switch function
|
Freely programmable |
|
Switching element function
|
Switchable |
|
Max. output current [mA]
|
250 |
|
Rise time [ms]
|
3 |
|
Short circuit resistance
|
yes |
|
Operating voltage range DC [V]
|
15 to 35 |
|
Reverse polarity protection
|
for operating voltage |
|
electrical connection:
|
M12x1 |
|
Fastening type
|
with male thread |
|
installation position
|
arbitrary |
|
Pneumatic connection
|
Male thread G1/2 |
|
Product weight [g]
|
230 |
|
Housing material
|
ABS |
|
From medium contacting materials
|
High-alloyed stainless steels |
|
Display type
|
4 digit alphanumeric |
|
Presentable unit(s)
|
MPa |
|
Switching status indicator
|
LED red |
|
Setting options
|
Via display and buttons |
|
Tamper-proof fuse
|
PIN code |
|
Settings range threshold value [%]
|
0.5 to 100 |
|
Settings range hysteresis [%]
|
0.5 to 99.5 |
|
Protection category
|
IP65 |
|
Corrosion resistant class KBK
|
4 - particularly severe corrosion stress |
|
Gasket material
|
NBR |
|
Weight
|
230 g / Pcs |
|
GTIN
|
4052568257569 |
|
Customs duty number
|
90262020 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: SPAW (english) , Data sheet |
