Permission
|
RCM mark |
|
CE certificate (see declaration of conformity)
|
acc. to EU-EMV Directive |
|
KC-mark
|
KC-EMV |
|
Material information
|
Copper and PTFE-free |
|
Measurement principle
|
pneumatic |
|
Recording range [Mikrometer]
|
20 to 200 |
|
Operating pressure [bar]
|
4 to 7 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
ambient temperature [°C]
|
0 to 50 |
|
Repeatability switch point
|
± 2.5 µm recording range 30 µm to 150 µm |
|
Max. output current [mA]
|
100 |
|
Short circuit resistance
|
Cycling |
|
Operating voltage range DC [V]
|
22.8 to 26.4 |
|
Reverse polarity protection
|
for all electrical connections |
|
electrical connection:
|
M12x1 |
|
Fastening type
|
With throughway bores |
|
Pneumatic connection
|
QS-6 |
|
Product weight [g]
|
510 |
|
Housing material
|
PA reinforced |
|
Display type
|
Illuminating LCD Multiple |
|
Setting options
|
Teach-in |
|
Tamper-proof fuse
|
Electronic locking |
|
Protection category
|
IP65 |
|
Weight
|
510 g / Pcs |
|
GTIN
|
4052568193782 |
|
Customs duty number
|
90318020 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: SOPA (english) , Data sheet |
