Design
|
Block structure |
|
Material information
|
Copper and PTFE-free |
|
Measurement principle
|
Reed magnetic |
|
ambient temperature [°C]
|
-20 to 70 |
|
Control output
|
Bipolar contact |
|
Switching element function
|
NO contact |
|
Reproducibility of the switching value
|
± 0,1 mm |
|
Switch on time [ms]
|
0,5 |
|
Max. output current [mA]
|
1.000 |
|
Max. switching capacity AC [Voltampere]
|
40 |
|
Max. switching capacity DC [W]
|
40 |
|
Short circuit resistance
|
no |
|
Overload resistant
|
Not available |
|
Operating voltage range DC [V]
|
0 to 200 |
|
Reverse polarity protection
|
no |
|
electrical connection:
|
2-wire |
|
Fastening type
|
With Accessories |
|
Product weight [g]
|
100 |
|
Housing material
|
PC |
|
Ambient temperature for moving cable placements [°C]
|
-5 to 70 |
|
Protection category
|
IP67 |
|
CE certificate (see declaration of conformity)
|
to EU low voltage directive |
|
Operating voltage range AC [V]
|
0 to 250 |
|
Complies to standard
|
DIN EN 60947-5-2 |
|
Switch off time [ms]
|
0,03 |
|
Max. switching frequency [hz]
|
500 |
|
Max. output current AC [mA]
|
1.000 |
|
Max. output current DC [mA]
|
1.000 |
|
Voltage drop [V]
|
<= 0 V |
|
Residual current [mA]
|
0 |
|
Connection outlet direction
|
along |
|
Cable length [MTR]
|
2,5 |
|
Cable sleeve material
|
PVC |
|
Torque [Nm]
|
2,9 |
|
Surge voltage strength [kV]
|
4 |
|
Degree of contamination
|
3 |
|
Weight
|
100 g / Pcs |
|
GTIN
|
4052568003685 |
|
Customs duty number
|
85365080 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: SMX-1 (english) , Data sheet |
