Design
|
Block structure |
|
Material information
|
Copper and PTFE-free |
|
Measurement principle
|
Reed magnetic |
|
ambient temperature [°C]
|
-20 to 70 |
|
Control output
|
Bipolar contact |
|
Switching element function
|
NO contact |
|
Reproducibility of the switching value
|
± 0,1 mm |
|
Switch on time [ms]
|
<= 0,5 ms |
|
Max. output current [mA]
|
1.000 |
|
Max. switching capacity AC [Voltampere]
|
27 |
|
Max. switching capacity DC [W]
|
27 |
|
Short circuit resistance
|
no |
|
Overload resistant
|
Not available |
|
Operating voltage range DC [V]
|
12 to 27 |
|
Reverse polarity protection
|
no |
|
electrical connection:
|
3-wire |
|
Fastening type
|
With Accessories |
|
installation position
|
arbitrary |
|
Product weight [g]
|
110 |
|
Housing material
|
PET reinforced |
|
Ambient temperature for moving cable placements [°C]
|
-5 to 70 |
|
Protection category
|
IP67 |
|
Permission
|
RCM mark |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Operating voltage range AC [V]
|
12 to 27 |
|
Switching status indicator
|
LED yellow |
|
Connection outlet direction
|
along |
|
Cable length [MTR]
|
2,5 |
|
Cable sleeve material
|
TPE-U(PUR) |
|
Weight
|
110 g / Pcs |
|
GTIN
|
4052568117009 |
|
Customs duty number
|
85365019 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Data sheet |
