Complies to standard
|
EN 60947-5-2 |
|
Permission
|
RCM mark |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Material information
|
Copper and PTFE-free |
|
Measurement switching distance [mm]
|
2,0 |
|
Secured safety distance [mm]
|
1,60 |
|
Reduction factors
|
aluminium = 0,45 |
|
ambient temperature [°C]
|
-25 to 85 |
|
Repeatability [mm]
|
0,10 |
|
Control output
|
NPN |
|
Switching element function
|
NO contact |
|
Max. switching frequency [hz]
|
1.200 |
|
Max. switching frequency DC [hz]
|
1.200 |
|
Max. output current depending on temperature
|
150 mA at <= 85 °C |
|
Voltage drop [V]
|
3,2 |
|
Short circuit resistance
|
Cycling |
|
Operating voltage range DC [V]
|
10 to 30 |
|
residual ripple
|
10 % |
|
Empty run current [mA]
|
<= 30 mA |
|
Reverse polarity protection
|
for all electrical connections |
|
electrical connection:
|
M8x1 |
|
size
|
15x20x30 mm |
|
Fastening type
|
With throughway bores |
|
Integration type
|
flush |
|
Product weight [g]
|
120 |
|
Housing material
|
Zinc pressure cast |
|
Switching status indicator
|
LED yellow |
|
Protection category
|
IP67 |
|
Weight
|
120 g / Pcs |
|
GTIN
|
4052568069766 |
|
Customs duty number
|
85365019 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Proximity sensors SIE (english) , Data sheet |
