Complies to standard
|
EN 60947-5-2 |
|
Permission
|
RCM mark |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Material information
|
Copper and PTFE-free |
|
Measurement switching distance [mm]
|
15,0 |
|
Secured safety distance [mm]
|
12,15 |
|
Reduction factors
|
aluminium = 0,5 |
|
ambient temperature [°C]
|
-25 to 70 |
|
Repeatability [mm]
|
0,75 |
|
Control output
|
PNP |
|
Switching element function
|
NC contact |
|
Max. switching frequency [hz]
|
700 |
|
Max. output current [mA]
|
200 |
|
Voltage drop [V]
|
<= 2 V |
|
Short circuit resistance
|
Cycling |
|
Operating voltage range DC [V]
|
15 to 30 |
|
residual ripple
|
± 20 % |
|
Empty run current [mA]
|
<= 10 mA |
|
Reverse polarity protection
|
for all electrical connections |
|
electrical connection:
|
3 pin |
|
Cable length [MTR]
|
2,5 |
|
Cable sleeve material
|
TPE-U(PUR) |
|
size
|
M30x1,5 |
|
Fastening type
|
With locking nut |
|
Integration type
|
not flush |
|
Product weight [g]
|
150,0 |
|
Housing material
|
PBTP |
|
Switching status indicator
|
LED yellow |
|
Protection category
|
IP67 |
|
Ambient temperature for moving cable placements [°C]
|
-5 to 70 |
|
Surge voltage strength [kV]
|
0,8 |
|
Degree of contamination
|
3 |
|
Hysteresis [mm]
|
<= 1,65 mm |
|
Torque [Nm]
|
40 |
|
Weight
|
150,0 g / Pcs |
|
GTIN
|
4052568069568 |
|
Customs duty number
|
85365019 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Proximity sensors SIE (english) , Data sheet |
