Permission
|
RCM mark |
|
CE certificate (see declaration of conformity)
|
acc. to EU-EMV Directive |
|
KC-mark
|
KC-EMV |
|
Material information
|
RoHs compliant |
|
Measured parameter
|
Mass flow |
|
Flow direction
|
Uni-directional |
|
Measurement principle
|
Thermic |
|
Measurement process
|
Heat Loss |
|
Durchflusserfassungsbereich Anfangswert [l/min]
|
0 |
|
Durchflusserfassungsbereich Endwert [l/min]
|
1 |
|
Operating pressure [bar]
|
-0.9 to 10 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [6:4:4] |
|
Medium temperature [°C]
|
0 to 50 |
|
ambient temperature [°C]
|
0 to 50 |
|
Nominal temperature [°C]
|
23 |
|
Repeatability in ± %FS []
|
1 |
|
Analogue output
|
1 - 5 V |
|
Rise time [ms]
|
3 |
|
Min. load resistance voltage output [Kilo-Ohm]
|
20 |
|
Short circuit resistance
|
yes |
|
Overload resistant
|
Available |
|
Operating voltage range DC [V]
|
22 to 26 |
|
Empty run current [mA]
|
<= 17 mA |
|
Reverse polarity protection
|
for all electrical connections |
|
Electrical connection 1, connection type
|
cable |
|
Electrical connection 1, connection technology
|
Open end |
|
Electrical connection 1, number of pins / wires
|
3 |
|
Cable length [MTR]
|
2,5 |
|
Cable sleeve material
|
TPE-U(PUR) |
|
Fastening type
|
Leitungseinbau |
|
installation position
|
arbitrary |
|
Pneumatic connection
|
for push-in fitting exterior diameter 4 mm |
|
Product weight [g]
|
40 |
|
Housing material
|
PA reinforced |
|
Protection category
|
IP40 |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Weight
|
40 g / Pcs |
|
Customs duty number
|
90268020 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: SFTE (english) , Data sheet |
