Model series
|
L |
|
Nominal width DN
|
54 |
|
Construction set up
|
Piston pusher |
|
Actuation type
|
pneumatic |
|
Sealing principle
|
Soft |
|
Exhaust function
|
Cannot be throttled |
|
Reset mode
|
Mechanical spring |
|
Control type
|
Direct |
|
Valve function
|
3/2 closed monostable |
|
Operating pressure [bar]
|
0 to 50 |
|
Control pressure [bar]
|
9 to 50 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Material information
|
LABS containing materials included |
|
Medium temperature [°C]
|
5 to 50 |
|
ambient temperature [°C]
|
5 to 50 |
|
Food compatibility
|
See expanded material information |
|
CE certificate (see declaration of conformity)
|
to EU pressure vessel directive |
|
installation position
|
arbitrary |
|
Product weight [g]
|
6.900 |
|
Pneumatic connection 3
|
G1/2 |
|
Control air 12 connection
|
G1/4 |
|
Control air supply
|
external |
|
Piston pusher material
|
Aluminium wrought alloy |
|
Seals material
|
NBR |
|
Housing material
|
Aluminium wrought alloy |
|
Weight
|
6.900 g / Pcs |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Pneumatic components for high-pressure applications (english) , Data sheet |
