Operating length [MTR]
|
4,8 |
|
Exterior diameter [mm]
|
11,7 |
|
Block length [MTR]
|
1,172 |
|
Flow relevant bending radius [mm]
|
65 |
|
Inside diameter [mm]
|
7,9 |
|
Winding diameter [mm]
|
51 |
|
Winding count
|
41 |
|
Temperature depending operating pressure [bar]
|
-0.95 to 13 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:-:-] |
|
Corrosion resistant class KBK
|
1 - low corrosion stress |
|
ambient temperature [°C]
|
-40 to 60 |
|
Nominal tightening torque [Nm]
|
12,5 |
|
Tolerance to nominal tightening torque
|
± 20 % |
|
Product weight [g]
|
480 |
|
Pneumatic connection 1
|
Male thread G3/8 |
|
Pneumatic connection 2
|
Male thread G3/8 |
|
colour
|
#009FE3 |
|
Shore hardness
|
A 87 ±3 |
|
Connection thread material
|
brass |
|
Material information
|
Copper and PTFE-free |
|
Bend protection material
|
POM |
|
Hose material
|
TPE-U(PU) |
|
Weight
|
480 g / Pcs |
|
GTIN
|
4052568167240 |
|
Customs duty number
|
39173900 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Spiral plastic tubing (english) , Data sheet |
