Operating length [MTR]
|
7,5 |
|
Exterior diameter [mm]
|
7,8 |
|
Block length [MTR]
|
0,43 |
|
Inside diameter [mm]
|
6,2 |
|
Winding diameter [mm]
|
75 |
|
Winding count
|
43 |
|
Temperature depending operating pressure [bar]
|
-0.95 to 17.2 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:-:-] |
|
Corrosion resistant class KBK
|
1 - low corrosion stress |
|
ambient temperature [°C]
|
-30 to +80 |
|
Nominal tightening torque [Nm]
|
11 |
|
Tolerance to nominal tightening torque
|
± 20 % |
|
Product weight [g]
|
298 |
|
Pneumatic connection 1
|
Male thread G1/4 |
|
Pneumatic connection 2
|
Male thread G1/4 |
|
colour
|
#009FE3 |
|
Connection thread material
|
Brass |
|
Material information
|
RoHs compliant |
|
Bend protection material
|
Steel |
|
Hose material
|
Polyamide 12 |
|
Weight
|
298 g / Pcs |
|
GTIN
|
4052568113506 |
|
Customs duty number
|
39173300 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Spiral plastic tubing (english) , Data sheet |
