Plate spring pressure gauge vert-ical, 100mm, 0 - 1,6 bar

Suitable:

For use in gaseous, liquid, viscous and aggressive measured material, in which the medium may not be in contact with the measuring device. The medium is separated from the meter using a diaphragm so that the medium only affects the diaphragm. In order to provide proper use at high temperatures, we require your specific operating conditions for the configuration of the plate spring pressure gauge. Contact our technician for this purpose.

Materials:

Measuring element / diaphragm: <= 2.5 bar: 1.4571, > 2.5 bar: 1.4568, indicator: copper alloy, housing with upper measuring flange: black cast iron, bottom measuring flange: steel, seal: NBR, window: instrument plate glass

Connection thread:

G 1/2" *

Measuring flange diameter:

100 mm (160 mm for mbar-scale)

Overload capability:

3 x scale value (max. 40 bar), violating the lower measurement value is not permitted.

Class:

1,6

Temperature range:

Ambience: -20°C to +60°C, measured material: -20°C to +100°C

Protection class:

IP 54

Note:

WIKA Type 422.12

Optional:

ISO calibration certificate (factory calibration certificate) acc. to DIN EN ISO 17025, VDI and data sheet DAkkS-DKD-MB-3 with 5 measurement points
