Model series
|
L |
|
size
|
186 |
|
Construction set up
|
Fibre filter |
|
Filter porosity [Mikrometer]
|
0,01 |
|
Condensate drain
|
Manually |
|
Operating pressure [bar]
|
0 to 50 |
|
Operating medium
|
Inert gases |
|
Information about operating and control medium
|
Oiled operation not possible |
|
Air purity class at the output
|
Compressed air to ISO 8573-1:2010 [1:4:2] |
|
Max. normal flow for air purity class [l/min]
|
18.980 |
|
Min. normal flow for air unit class [l/min]
|
6.326 |
|
Filter effective degree [%]
|
100 |
|
Max. condensate amount [ml]
|
400 |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Food compatibility
|
See expanded material information |
|
Medium temperature [°C]
|
5 to 60 |
|
ambient temperature [°C]
|
5 to 60 |
|
Bearing temperature [°C]
|
-10 to 60 |
|
CE certificate (see declaration of conformity)
|
to EU pressure vessel directive |
|
Fastening type
|
pipe installation |
|
installation position
|
vertical ± 5° |
|
Housing material
|
Aluminium wrought alloy |
|
Filter material
|
Borosilicate fibre |
|
Clamps material
|
High-alloyed stainless steels |
|
Seals material
|
NBR |
|
Material information
|
LABS containing materials included |
|
Product weight [g]
|
21.000 |
|
Volume
|
6,7 |
|
Weight
|
21.000 g / Pcs |
|
Customs duty number
|
84213925 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Pneumatic components for high-pressure applications (english) , Data sheet |
