Permission
|
RCM mark |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Material information
|
Copper and PTFE-free |
|
Measured parameter
|
Differential pressure |
|
Measurement process
|
Pneumatic electric differential pressure switch |
|
Operating pressure [bar]
|
-1 to 8 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Medium temperature [°C]
|
-20 to 60 |
|
ambient temperature [°C]
|
-20 to 60 |
|
Control output
|
PNP |
|
Switching element function
|
NO contact |
|
Max. switching frequency [hz]
|
70 |
|
Max. output current [mA]
|
350 |
|
Short circuit resistance
|
yes |
|
Operating voltage range DC [V]
|
12 to 30 |
|
electrical connection:
|
3-wire |
|
Cable length [MTR]
|
2,5 |
|
Fastening type
|
on mounting frames 2n |
|
installation position
|
arbitrary |
|
Pneumatic connection
|
M5 |
|
Product weight [g]
|
240 |
|
Housing material
|
Zinc pressure cast |
|
Switching status indicator
|
LED yellow |
|
Settings range threshold value [bar]
|
-0.8 to 8 |
|
Protection category
|
IP67 |
|
Weight
|
240 g / Pcs |
|
GTIN
|
4052568008819 |
|
Customs duty number
|
85369095 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Data sheet , Group data sheet: M5-Compactsystem |
