Permission
|
CCC |
|
CE certificate (see declaration of conformity)
|
to EU low voltage directive |
|
Measured parameter
|
Relative pressure |
|
Measurement process
|
Pneumatic electric pressure converter |
|
Operating pressure [bar]
|
0 to 8 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible |
|
Medium temperature [°C]
|
0 to 60 |
|
ambient temperature [°C]
|
0 to 60 |
|
Switching element function
|
changeover contact |
|
Max. switching frequency [hz]
|
1 |
|
Minimum load current
|
100 |
|
electrical connection:
|
3 connection slots |
|
Fastening type
|
on mounting frames 1n |
|
installation position
|
arbitrary |
|
Pneumatic connection
|
G1/8 |
|
Product weight [g]
|
50 |
|
Housing material
|
PA |
|
Switch contact material
|
|
|
Protection category
|
IP67 |
|
Operating voltage range AC [V]
|
12 to 250 |
|
Operating voltage range DC [V]
|
12 to 250 |
|
Cable length [MTR]
|
0,50 |
|
Cable sleeve material
|
PVC |
|
Electrical connection: material
|
Tin plated |
|
Diaphragm material
|
TPE-U(PU) |
|
Control output
|
Contact |
|
Switch function
|
Threshold value with fixed hysteresis |
|
Maximum switch on point [bar]
|
2 |
|
Switch off point minimum [bar]
|
0,5 |
|
Weight
|
50 g / Pcs |
|
GTIN
|
4052568001230 |
|
Customs duty number
|
85369095 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Data sheet |
