Line designation
|
Without sign holder |
|
Product weight [g]
|
16 |
|
Electrical connection 1, function
|
Field device screen |
|
Electrical connection 1, design
|
Angular |
|
Electrical connection 1, connection type
|
socket / container / …. |
|
Electrical connection 1, cable output
|
straight |
|
Electrical connection 1, connection technology
|
Wiring diagram S |
|
Electrical connection 1, number of pins / wires
|
2 |
|
Electrical connection 1, occupied pin / wire
|
2 |
|
Electrical connection 1, fastening type
|
Ratcheting lock |
|
Electrical connection 2, function
|
Control screen |
|
Electrical connection 2, connection type
|
cable |
|
Electrical connection 2, connection technology
|
Open end |
|
Electrical connection 2, number of pins / wires
|
2 |
|
Electrical connection 2, occupied pin / wire
|
2 |
|
Operating voltage range DC [V]
|
0 to 60 |
|
Current carrying capacity at 40°C [A]
|
3 |
|
Cable length [MTR]
|
1,0 |
|
Line properties
|
For static applications |
|
Cable diameter [mm]
|
3,4 |
|
Cable set up
|
2x0,14 |
|
Protection category
|
IP40 |
|
Information about protection category
|
In mounted condition |
|
ambient temperature [°C]
|
-5 to 60 |
|
Material information
|
RoHs compliant |
|
Cable sleeve material
|
TPE-U(PUR) |
|
Cable shield colour
|
#C6C6C6 |
|
Housing material
|
POM |
|
Housing colour
|
#000000 |
|
Insulation sleeve material
|
PVC |
|
Conductor - nominal cross-section [mm²]
|
0,14 |
|
Plug contacts material
|
Copper allow |
|
Wire ends
|
Unshielded |
|
installation position
|
arbitrary |
|
Weight
|
16 g / Pcs |
|
GTIN
|
4052568057442 |
|
Customs duty number
|
85444290 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: NEBV-HSG2 (english) , Data sheet |
