Cable length [MTR]
|
0,20 |
|
Material information
|
RoHs compliant |
|
Corrosion resistant class KBK
|
0 - No corrosion stressing |
|
Line designation
|
Without sign holder |
|
Electrical connection 1, function
|
Field device screen |
|
Electrical connection 1, design
|
Angular |
|
Electrical connection 1, connection type
|
Plug |
|
Electrical connection 1, cable output
|
straight |
|
Electrical connection 1, connection technology
|
RJ45 |
|
Electrical connection 1, number of pins / wires
|
8 |
|
Electrical connection 1, occupied pin / wire
|
8 |
|
Electrical connection 2, function
|
Control screen |
|
Electrical connection 2, connection type
|
Plug |
|
Electrical connection 2, connection technology
|
RJ45 |
|
Electrical connection 2, number of pins / wires
|
8 |
|
Electrical connection 2, occupied pin / wire
|
8 |
|
Operating voltage range DC [V]
|
0 to 50 |
|
Line properties
|
Standard |
|
Bending radius, permanent cable placement [mm]
|
24 |
|
Cable diameter [mm]
|
5,0 |
|
Cable set up
|
4 x 2 x 0,16 mm² |
|
Conductor - nominal cross-section [mm²]
|
0,16 |
|
Protection category
|
IP20 |
|
Information about protection category
|
In mounted condition |
|
ambient temperature [°C]
|
-20 to 60 |
|
Degree of contamination
|
2 |
|
Cable sleeve material
|
PVC |
|
Cable shield colour
|
#C6C6C6 |
|
Product weight [g]
|
15 |
|
Current carrying capacity at 40°C [A]
|
1,50 |
|
Housing material
|
PVC |
|
Housing colour
|
#C6C6C6 |
|
Insulation sleeve material
|
PVC |
|
Surge voltage strength [kV]
|
2,5 |
|
Test conditions line
|
Test conditions on request |
|
Electrical connection 2, design
|
Angular |
|
Electrical connection 2, cable output
|
straight |
|
Schirmung
|
yes |
|
Weight
|
15 g / Pcs |
|
Customs duty number
|
85444290 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: CMMT-AS (english) , Data sheet |
