Product weight [g]
|
500 |
|
Material information
|
RoHs compliant |
|
Permission
|
c UL us - Recognized (OL) |
|
Fastening type
|
With throughway bores |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Operating pressure [bar]
|
-0.9 to 10 |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Medium temperature [°C]
|
-5 to 50 |
|
ambient temperature [°C]
|
-5 to 50 |
|
Nominal width [mm]
|
14,5 |
|
Pitch dimension [mm]
|
72 |
|
Actuation type
|
Electrical |
|
installation position
|
arbitrary |
|
Hand assist actuation
|
tentative |
|
Reset mode
|
Mechanical spring |
|
Control type
|
Direct |
|
Flow direction
|
Not reversible |
|
Control pressure [bar]
|
2 to 10 |
|
Nominal operating voltage DC [V]
|
24 |
|
Permitted voltage oscillations
|
± 10 % |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Bearing temperature [°C]
|
-20 to 40 |
|
Protection category
|
IP65 |
|
control medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Seals material
|
NBR |
|
Weight
|
500 g / Pcs |
|
GTIN
|
4052568115562 |
|
Customs duty number
|
84819000 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Valve terminal VTSA / VTSA-F (english) , Data sheet |
