Product weight [g]
|
30 |
|
Operating voltage range DC [V]
|
0 to 24 |
|
Operating voltage range AC [V]
|
0 to 250 |
|
Current carrying capacity at 40°C [A]
|
16 |
|
Cable screwing
|
M20x1,5 |
|
Cable diameter [mm]
|
8 to 10 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-25 to 80 |
|
Housing material
|
PA reinforced |
|
Housing colour
|
#000000 |
|
Seals material
|
VMQ |
|
Conductor - nominal cross-section [mm²]
|
1,5 |
|
Material information
|
LABS containing materials included |
|
Based on standard
|
EN 175301-803 |
|
Cable output
|
Angled |
|
Electrical connection 1, design
|
Angular |
|
Electrical connection 1, connection type
|
socket / container / …. |
|
Electrical connection 1, connection technology
|
Wiring diagram shape A acc. to EN 175301-803 |
|
Electrical connection 1, number of pins / wires
|
3 |
|
Electrical connection 1, fastening type
|
on solenoid valve with central screw M3 |
|
Electrical connection 2, connection technology
|
Screw clamp |
|
Information about protection category
|
In mounted condition |
|
Screws material
|
Steel |
|
Weight
|
30 g / Pcs |
|
GTIN
|
4052568051952 |
|
Customs duty number
|
85366990 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: MSSD-N (english) , Data sheet |
