installation position
|
arbitrary |
|
Min. tightening time [ms]
|
10 |
|
Power-on time
|
100% |
|
Coil characteristic value
|
230 V AC: 50/60 Hz, pull-in power 9 VA, holding power 7 VA |
|
Permitted voltage oscillations
|
± 10 % |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
-5 to 40 |
|
Product weight [g]
|
55 |
|
electrical connection:
|
Wiring diagram Form A acc. to EN 175301-803 |
|
Fastening type
|
With Knurled nut |
|
Material information
|
RoHs compliant |
|
Winding material
|
Copper |
|
Performance factor cos {phi}
|
0.7 |
|
CE certificate (see declaration of conformity)
|
to EU low voltage directive |
|
Maritime classification
|
see Certificate |
|
Switching position display
|
no |
|
Permitted frequency oscillations
|
± 5 % |
|
Max. tightening torque Socket [Nm]
|
0,4 |
|
Solenoid material
|
Duroplast |
|
Weight
|
55 g / Pcs |
|
GTIN
|
4052568066017 |
|
Customs duty number
|
85059029 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Solenoid coils (english) , Data sheet |
