size
|
6 |
|
Model series
|
MSE |
|
installation position
|
Horizontal ± 5° |
|
Valve function
|
2/2 open monostable |
|
Operating pressure [bar]
|
3.5 to 10 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation not possible |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Bearing temperature [°C]
|
-10 to 60 |
|
Medium temperature [°C]
|
0 to 50 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
0 to 50 |
|
Permission
|
RCM mark |
|
Product weight [g]
|
3.300 |
|
Pneumatic connection 1
|
G1/2 |
|
Pneumatic connection 2
|
G1/2 |
|
Seals material
|
NBR |
|
Housing material
|
Aluminium die casting |
|
Cover material
|
PA reinforced, PA reinforced |
|
Fieldbus interface
|
Socket Sub-D, 9 pin |
|
Operating voltage range DC electronics / sensor [V]
|
18 to 30 |
|
Operating voltage DC load voltage [V]
|
18 to 26.4 |
|
Reverse polarity protection
|
for operating voltage connections |
|
Presentable unit(s)
|
kPa |
|
Flow measurement range starting value [l/min]
|
50 |
|
Flow measurement range end value [l/min]
|
5.000 |
|
Accuracy flow value
|
± (3% o.m.v. + 0,3% FS) |
|
Pressure measurement range starting value [bar]
|
0 |
|
Pressure measurement range end value [bar]
|
14 |
|
Accuracy FS []
|
3 |
|
Weight
|
3.300 g / Pcs |
|
GTIN
|
4052568254339 |
|
Customs duty number
|
84811005 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: MSE6-E2M (english) , Data sheet |
