Construction set up
|
Rotary disc |
|
Actuation type
|
Manually |
|
Exhaust function
|
Cannot be throttled |
|
Control type
|
Direct |
|
Valve function
|
3/2 bistable |
|
Operating pressure [bar]
|
0 to 18 |
|
C-value []
|
30,8 |
|
b-value
|
0.57 |
|
Normal nominal flow [l/min]
|
8.700 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Material information
|
Copper and PTFE-free |
|
Medium temperature [°C]
|
-10 to 60 |
|
ambient temperature [°C]
|
-10 to 60 |
|
Food compatibility
|
See expanded material information |
|
Fastening type
|
pipe installation |
|
installation position
|
arbitrary |
|
Flow direction
|
Not reversible |
|
Product weight [g]
|
580 |
|
Pneumatic connection 1
|
G1/2 |
|
Pneumatic connection 2
|
G1/2 |
|
Pneumatic connection 3
|
G1/2 |
|
Seals material
|
TPE-U(PU) |
|
Housing material
|
Aluminium die casting |
|
Weight
|
580 g / Pcs |
|
GTIN
|
4052568090807 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: On-off/soft-start valves, MS series (english) , Data sheet |
