Exhaust function
|
Can be throttled |
Actuation type
|
pneumatic |
installation position
|
arbitrary |
Hand assist actuation
|
none |
Construction set up
|
Piston seat |
Reset mode
|
Mechanical spring |
Control type
|
Direct |
Control air supply
|
external |
Flow direction
|
Not reversible |
Valve function
|
2/2 |
Operating pressure [bar]
|
4 to 18 |
b-value
|
0.54 |
C-value []
|
11,22 |
Normal nominal flow [l/min]
|
2.800 |
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
Food compatibility
|
See expanded material information |
Medium temperature [°C]
|
-10 to 60 |
ambient temperature [°C]
|
-10 to 60 |
Product weight [g]
|
650 |
Fastening type
|
pipe installation |
Pneumatic connection 1
|
G1/4 |
Pneumatic connection 2
|
G1/4 |
Material information
|
Copper and PTFE-free |
Seals material
|
NBR |
Housing material
|
Aluminium die casting |
Weight
|
650 g / Pcs |
GTIN
|
4052568164331 |
Customs duty number
|
84812090 |
RoHS compliant
|
Yes |
Manufacturer
|
Festo |
Document
|
Group data sheet: On-off/soft-start valves, MS series (english) , Data sheet |
