size
|
12 |
|
Model series
|
MS |
|
installation position
|
arbitrary |
|
Construction set up
|
Pre-controlled membrane control valve |
|
Controller function
|
Output pressure constant |
|
pressure display
|
with pressure gauge |
|
Operating pressure [bar]
|
1.15 to 8 |
|
Pressure regulation range [bar]
|
0.15 to 6 |
|
Max. pressure hysteresis [bar]
|
0,04 |
|
Flow secondary venting [l/min]
|
<= 600 l/>in |
|
Normal nominal flow [l/min]
|
12000 to 21000 |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Bearing temperature [°C]
|
-10 to 60 |
|
Medium temperature [°C]
|
10 to 50 |
|
ambient temperature [°C]
|
10 to 50 |
|
Product weight [g]
|
4.000 |
|
Fastening type
|
pipe installation |
|
Pneumatic connection 1
|
Connection plate |
|
Pneumatic connection 2
|
Connection plate |
|
Cover material
|
PA |
|
Material information
|
RoHs compliant |
|
Cover down material
|
Aluminium wrought alloy |
|
Seals material
|
NBR |
|
Spring material
|
spring steel |
|
Housing material
|
Aluminium die casting |
|
Diaphragm material
|
NBR |
|
Valve tappet material
|
NBR |
|
Operating voltage range DC [V]
|
21.6 to 26.4 |
|
Max. electrical power consumption [W]
|
3,6 |
|
Max. power input [A]
|
0,15 |
|
Nominal operating voltage DC [V]
|
24 |
|
residual ripple
|
10 % |
|
Signal range analogue input
|
0 - 10 V |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
Protection category
|
IP65 |
|
Weight
|
4.000 g / Pcs |
|
GTIN
|
4052568211882 |
|
Customs duty number
|
84811099 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: Pressure regulators, MS series (english) , Data sheet |
