installation position
|
arbitrary |
|
Construction set up
|
Branching module |
|
Operating pressure [bar]
|
0 to 20 |
|
Normal nominal flow in main flow direction 1 -> 2 [l/min]
|
25000 to 42000 |
|
Operating medium
|
Compressed air to ISO8573-1:2010 [-:-:-] |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Bearing temperature [°C]
|
-10 to 60 |
|
Medium temperature [°C]
|
-10 to 60 |
|
ambient temperature [°C]
|
-10 to 60 |
|
Product weight [g]
|
3.000 |
|
Pneumatic connection 1
|
Battery module |
|
Pneumatic connection 2
|
Battery module |
|
Pneumatic connection 3
|
G2 |
|
Pneumatic connection 4
|
G1 |
|
Material information
|
Copper and PTFE-free |
|
Housing material
|
Aluminium die casting |
|
Weight
|
3.000 g / Pcs |
|
GTIN
|
4052568179755 |
|
Customs duty number
|
76169990 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Data sheet , Group data sheet: Abzweigmodule/Verteilerblöcke, Baureihe MS |
