Nominal width [mm]
|
10 |
|
Actuation type
|
Electrical |
|
Sealing principle
|
Hard |
|
installation position
|
arbitrary |
|
Construction set up
|
Piston pusher |
|
Reset mode
|
Spring magnetic |
|
Safety instructions
|
Safety position MPYE: Move to the blocked centre position if there is a supply line break. |
|
Control type
|
Direct |
|
Flow direction
|
Not reversible |
|
Valve function
|
5/3 closed |
|
Reverse polarity protection
|
For target value |
|
Operating pressure [bar]
|
0 to 10 |
|
b-value
|
0.21 |
|
C-value []
|
9,00 |
|
Normal nominal flow [l/min]
|
2.000 |
|
Limit frequency [hz]
|
70 |
|
Max. hysteresis [%]
|
0,4 |
|
Operating voltage range DC [V]
|
17 to 30 |
|
residual ripple
|
5 % |
|
TARGET / ACTUAL value
|
Current type 4 - 20 mA |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [6:4:4] |
|
Information about operating and control medium
|
Oiled operation not possible |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
KC-mark
|
KC-EMV |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Medium temperature [°C]
|
5 to 40 |
|
Protection category
|
IP65 |
|
ambient temperature [°C]
|
0 to 50 |
|
Permission
|
RCM mark |
|
Product weight [g]
|
685 |
|
electrical connection:
|
M12x1 |
|
Fastening type
|
With throughway bores |
|
Pneumatic connection 1
|
G3/8 |
|
Pneumatic connection 2
|
G3/8 |
|
Pneumatic connection 3
|
G3/8 |
|
Pneumatic connection 4
|
G3/8 |
|
Pneumatic connection 5
|
G3/8 |
|
Material information
|
RoHs compliant |
|
Cover material
|
ABS |
|
Seals material
|
NBR |
|
Housing material
|
aluminium |
|
Weight
|
685 g / Pcs |
|
GTIN
|
4052568129491 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: MPYE (english) , Data sheet |
