Additional functions
|
Spark suppression |
|
Fastening type
|
With throughway bores |
|
installation position
|
arbitrary |
|
Product weight [g]
|
40 |
|
electrical connection:
|
2 pin / 2 pin / 4-wire |
|
Operating voltage range DC [V]
|
12 to 53 |
|
Reverse polarity protection
|
for operating voltage |
|
Information about operation
|
Power supply must be able to deliver at least 1.85 A without a voltage breakthrough |
|
Information about power consumption
|
Low current phase 2,8 W, High current phase 17,1 W, Per channel |
|
Power-on time
|
100% |
|
Trigger signal range DC [V]
|
3 to 30 |
|
Information about incoming current
|
0,09 - 0,44 mA bei einem Triggersignal von 3 - 15 V |
|
Eingangswiderstand [Kilo-Ohm]
|
34 |
|
Cable length [MTR]
|
0,5 |
|
Line properties
|
For static applications |
|
Protection category
|
IP40 |
|
ambient temperature [°C]
|
-5 to 50 |
|
CE certificate (see declaration of conformity)
|
to EU EMC directive |
|
KC-mark
|
KC-EMV |
|
Material information
|
RoHs compliant |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Cable sleeve material
|
PVC |
|
Housing material
|
POM |
|
Weight
|
40 g / Pcs |
|
GTIN
|
4052568099121 |
|
Customs duty number
|
85371098 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Group data sheet: MHJ9-KMH (english) , Data sheet |
