Valve function
|
3/2 closed monostable |
|
Actuation type
|
Electrical |
|
Operating pressure [bar]
|
-0.9 to 8 |
|
Construction set up
|
Switch on valve |
|
Reset mode
|
Mechanical spring |
|
Protection category
|
IP66 |
|
Hand assist actuation
|
Ratcheting |
|
Flow direction
|
Not reversible |
|
Power-on time
|
100% |
|
Coil characteristic value
|
24 V DC: 3 W |
|
Operating medium
|
Compressed air to ISO 8573-1:2010 [7:4:4] |
|
Information about operating and control medium
|
Oiled operation possible (required in further operations) |
|
Corrosion resistant class KBK
|
2 - moderate corrosion stress |
|
Fastening type
|
CNOMO |
|
Material information
|
LABS containing materials included |
|
Permitted frequency oscillations
|
± 10 % |
|
CE certificate (see declaration of conformity)
|
to EU EX protection directive (ATEX) |
|
Insulation material class
|
H |
|
ATEX gas category
|
II 2G |
|
Ex ignition protection type gas
|
Ex db IIC T5 Gb |
|
ATEX dust category
|
II 2D |
|
Ex ignition protection type dust
|
Ex tb IIIC T100°C Db |
|
Ex protection approval outside of the EU
|
EPL Db (IEC-EX) |
|
Ex ambient temperature
|
-65°C<= Ta <= +55°C |
|
Certified awarding point
|
CML 15 ATEX 1119X |
|
Weight
|
850 g / Pcs |
|
GTIN
|
4052568169244 |
|
Customs duty number
|
84812090 |
|
RoHS compliant
|
Yes |
|
Manufacturer
|
Festo |
|
Document
|
Data sheet |
